| 多芯移动型软电缆 |
|
型号 |
产品名称 |
用途 |
导体长期允许 |
额定电压 |
标称截面 |
|
HR |
天然丁苯绝缘及护套多芯移动软电缆 |
适用于连接各种频繁移动式电气设备（电动葫芦、行车和各种探伤设备） |
-15 ~ +65 |
300
|
0.5 ~ 10 |
|
HRP |
天然丁苯绝缘及护套金属屏蔽多芯移动软电缆 |
-35 ~ +65 |
|||
|
HRF |
天然丁苯绝缘及氯丁护套多芯移动软电缆 |
||||
|
HRFP |
天然丁苯绝缘及氯丁护套金属屏蔽多芯移动软电缆 |
||||
|
YRJ |
天然丁苯绝缘及护套中心加强芯（屏蔽）多芯移动软电缆 |
同上、用于较高抗拉应力条件 |
-15 ~ +65 |
||
|
YRJG |
天然丁苯绝缘及护套自承式（屏蔽）多芯移动软电缆 |
||||
|
YRFJ |
天然丁苯绝缘及氯丁护套中心加强型（屏蔽）多芯移动软电缆 |
同上、具有自承负载能力 |
-35 ~ +65 |
||
|
YRFJG |
天然丁苯绝缘及氯丁护套自承式（屏蔽）多芯移动软电缆 |
|
电缆结构/尺寸表 |
|
型号 |
芯数x截面 |
电缆外径 |
20 ℃直流电阻 |
|
|
不镀锡丝 |
镀锡丝 |
|||
|
HR
YR
YXHR
HRF
YRF
YXFR |
1x1.0 |
6.8 |
19.5 |
20 |
|
2x1.0 |
9.5 |
20.5 |
21.0 |
|
|
3x1.0 |
10.0 |
20.5 |
21.0 |
|
|
4x1.0 |
10.7 |
20.5 |
21.0 |
|
|
5 x 1.0 |
11.6 |
20.5 |
21.0 |
|
|
6 x 1.0 |
12.5 |
20.5 |
21.0 |
|
|
7 x 1.0 |
12.9 |
20.5 |
21.0 |
|
|
8 x 1.0 |
16.5 |
20.5 |
21.0 |
|
|
9 x 1.0 |
17.0 |
20.5 |
21.0 |
|
|
10 x 1.0 |
17.7 |
20.5 |
21.0 |
|
|
12 x 1.0 |
19.5 |
20.5 |
21.0 |
|
|
14 x 1.0 |
17.7 |
20.5 |
21.0 |
|
|
16 x 1.0 |
18.6 |
20.5 |
21.0 |
|
|
18 x 1.0 |
19.5 |
20.5 |
21.0 |
|
|
20 x 1.0 |
20.4 |
20.5 |
21.0 |
|
|
24 x 1.0 |
23.0 |
20.5 |
21.0 |
|
|
1x1.5 |
7.3 |
13.3 |
13.7 |
|
|
2x1.5 |
10.2 |
14.0 |
14.4 |
|
|
3x1.5 |
10.7 |
14.0 |
14.4 |
|
|
4x1.5 |
11.5 |
14.0 |
14.4 |
|
|
5 x 1.5 |
12.4 |
14.0 |
14.4 |
|
|
6 x 1.5 |
14.4 |
14.0 |
14.4 |
|
|
7 x 1.5 |
14.9 |
14.0 |
14.4 |
|
|
8 x 1.5 |
17.7 |
14.0 |
14.4 |
|
|
9 x 1.5 |
18.2 |
14.0 |
14.4 |
|
|
10 x 1.5 |
19.1 |
14.0 |
14.4 |
|
|
12 x 1.5 |
21.0 |
14.0 |
14.4 |
|
|
14 x 1.5 |
19.1 |
14.0 |
14.4 |
|
|
16 x 1.5 |
20.0 |
14.0 |
14.4 |
|
|
18 x 1.5 |
21.0 |
14.0 |
14.4 |
|
|
20 x 1.5 |
22.0 |
14.0 |
14.4 |
|
|
24 x 1.5 |
25.8 |
14.0 |
14.4 |
|
|
5 x 2.5 |
16.3 |
7.98 |
8.21 |
|
|
6 x 2.5 |
18.0 |
7.98 |
8.21 |
|
|
7 x 2.5 |
19.4 |
7.98 |
8.21 |
|
|
8 x 2.5 |
22.5 |
7.98 |
8.21 |
|
|
9 x 2.5 |
23.2 |
7.98 |
8.21 |
|
|
10 x 2.5 |
24.4 |
7.98 |
8.21 |
|
|
12 x 2.5 |
27.0 |
7.98 |
8.21 |
|
|
14 x 2.5 |
24.4 |
7.98 |
8.21 |
|
|
16 x 2.5 |
26.7 |
7.98 |
8.21 |
|
|
18 x 2.5 |
28.0 |
7.98 |
8.21 |
|
|
20 x 2.5 |
29.4 |
7.98 |
8.21 |
|
|
24 x 2.5 |
34.2 |
7.98 |
8.21 |
|
|
注：以上规格为常用型，可根据用户要求定制特殊规格 |
||||
